RCLAMP2574N.TCT

Manufacturer Part Number: RCLAMP2574N.TCT Manufacturer / Brand: Semtech
Part of Description: 20V Clamp 40A (8/20µs) Ipp Tvs Diode Surface Mount SLP3020N10 Lead Free Status / RoHS Status: table_img Lead free / RoHS Compliant
Shipment Way: DHL/Fedex/TNT/UPS Datasheets:
100% original and authentic
100% test report if single part is over 500USD
100% damaged replacement guaranteed

Product parameters

Manufacturer Semtech Corporation
Series RailClamp®
Package Tape & Reel (TR),Cut Tape (CT)
Description TVS DIODE 2.5VWM 20VC SLP3020N10
Product Status Active
Manufacturer Standard Lead Time 22 Weeks
Operating Temperature -55°C ~ 85°C (TA)
Type Steering (Rail to Rail)
Unidirectional Channels 8
Voltage – Reverse Standoff (Typ) 2.5V (Max)
Voltage – Breakdown (Min) 2.7V
Voltage – Clamping (Max) @ Ipp 20V
Current – Peak Pulse (10/1000µs) 40A (8/20µs)
Power – Peak Pulse 1000W (1kW)
Power Line Protection Yes
Applications General Purpose
Capacitance @ Frequency 3.75pF @ 1MHz
Mounting Type Surface Mount
Package / Case 10-UDFN Exposed Pad
Supplier Device Package SLP3020N10
Base Product Number RCLAMP2574
  1. With a 2.5V voltage rating, this protection array is well-suited for applications where protection against ESD events is required in low-voltage circuits. It effectively clamps the voltage to a safe level, preventing damage to downstream components.
  2. The RCLAMP2574N.TCT features four channels, allowing it to provide comprehensive protection for multiple signal or data lines.
  3. This protection array is versatile and can be employed in various electronic systems, including but not limited to telecommunications, data communication, audio/video interfaces, and other applications where ESD protection is critical for reliable operation.
