Coaxial Switches

Competitive Pricing
Manufacturer Part Number: LGS80 Manufacturer / Brand: bowenjia-electronics
Part of Description: Coaxial Switches Lead Free Status / RoHS Status: table_img Lead free / RoHS Compliant
Ship From: HK/Shen Zhen Shipment Way: DHL/Fedex/TNT/UPS
Kind tips: The pictures are for reference only, the actual product shall prevail. In-Stock: 10,000
Stock: Can Ship within 5 Days Datasheets:
100% original and authentic
100% test report if single part is over 500USD
100% damaged replacement guaranteed

Product parameters

Manufacturer Shenzhen Bowenjia Electronics Co.,Ltd
Series LGS80
Package Bulk
Description Bowenjia Electronics is a manufacturer producing various kinds of coaxial switches and other high-frequency RF switches suitable for specialized equipment industries, aerospace, satellite, and other applications.

Please do not hesitate to contact us if you have any specific demand for coaxial switches.

We provide tailored products and services based on the specific needs of each customer, ensuring that every client receives high-quality and cost-effective solutions.

Our series of coaxial switches includes loadless coaxial switches (LGS8010 series) and load-bearing coaxial switches (LGS8011 series). The loadless coaxial switches include Single Pole Double Throw (SPDT) switches (LGS801012 series), Single Pole n Throw (SPnT) switches (LGS80101x series), Double Pole Double Throw (DPDT) switches (LGS801022 series), and Double Pole Triple Throw (DP3T) switches (LGS801023 series). The load-bearing coaxial switches include SPDT switches (LGS801112 series) and SPnT switches (LGS80111x series).

D/C Within 2 Years
Product Status Active
Operating Temperature -55°C ~ 85°C (TJ)
Voltage – Supply 12VDC(10V~14V);24VDC(20V~28V);28VDC(24V~32V);
Product Type: coaxial switches

Coaxial Switches Demo Video

G.A. Group is the authorized agent of Shenzhen Bowenjia Electronics Co., Ltd., handling its foreign trade operations. Shenzhen Bowenjia Electronics Co., Ltd. specializes in manufacturing various kinds of rf switches including Coaxial Switches, Waveguide Microwave rf switches, Surface Mount Microwave rf switches, Low PIM Microwave rf switches, High Power Coaxial rf switches, and Space-rated Microwave rf switches.

RF Switches (Microwave mechanical switches) can transmit and switch RF signals with nearly no distortion. They are mainly used in wireless communication, satellite communication, satellite navigation, fire control systems, precision instruments, automatic test equipment (ATE), etc.

The performance of microwave mechanical switches includes usable frequency range, switching repeatability, port voltage standing wave ratio (VSWR), insertion loss, power handling capability, channel isolation, passive intermodulation (PIM), switching life, switching time, operating temperature range, shock and vibration resistance, drive voltage and current, as well as size and weight.

Bowenjia Electronics was the first in China to release a full series of RF Switches products for multiple application scenarios, achieving satellite on-orbit operation and large-scale stable and reliable production. The company has accumulated mature reliability assessment processes and process control methods. The microwave switch products developed by the company have excellent low-temperature (-55°C) operating characteristics and high repeatability (insertion loss repeatability better than ±0.03dB), with a maximum operating frequency of up to 110GHz. The operating frequency reaches up to 110GHz for coaxial and up to 325GHz for waveguide, facilitating extensive development and service for microwave and millimeter-wave devices and components. The company’s RF Switches products have passed relevant test assessments.
